Diagram:
Section contains description of Process " GetDate.process " .
| Folder | Description |
|---|---|
| /PantherBW/ProcessDefinitions/BusinessLogic | The folder that contain the main procedures.... |
Name: Start
Description: The beginning of the process.
Input Parameters:
Name: End
Output Parameters:
Mapping table
| Target | Source |
|---|---|
| /[WHEN]<$_error>/GetInformationResponse/ResultCode | -1 |
| /[WHEN]<$_error>/GetInformationResponse/[IF]<$_error/ns:ErrorReport/StackTrace>/ResultMessage | $_error/ns:ErrorReport/StackTrace |
| /[OTHERWISE]/GetInformationResponse/ResultCode | 0 |
| /[OTHERWISE]/GetInformationResponse/[IF]<$SetDate/root/DateTime>/DateTime | $SetDate/root/DateTime |
Mapping tree
| Mapping |
|---|
[CHOOSE] [WHEN] < $_error > GetInformationResponse ResultCode = -1 [IF] < $_error/ns:ErrorReport/StackTrace > ResultMessage = $_error/ns:ErrorReport/StackTrace [OTHERWISE] GetInformationResponse ResultCode = 0 [IF] < $SetDate/root/DateTime > DateTime = $SetDate/root/DateTime |
Source code
| Mapping |
|---|
<xsl:choose xmlns:pd="http://xmlns.tibco.com/bw/process/2003" xmlns:xsl="http://www.w3.org/1999/XSL/Transform" xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:pfx="http://www.tibco.com/schemas/pantherbw/PantherBW/ProcessDefinitions/Schema/Schema.xsd" xmlns:ns="http://www.tibco.com/pe/EngineTypes">
<xsl:when test="$_error">
<pfx:GetInformationResponse>
<pfx:ResultCode>
<xsl:value-of select="-1"/>
</pfx:ResultCode>
<xsl:if test="$_error/ns:ErrorReport/StackTrace">
<pfx:ResultMessage>
<xsl:value-of select="$_error/ns:ErrorReport/StackTrace"/>
</pfx:ResultMessage>
</xsl:if>
</pfx:GetInformationResponse>
</xsl:when>
<xsl:otherwise>
<pfx:GetInformationResponse>
<pfx:ResultCode>
<xsl:value-of select="0"/>
</pfx:ResultCode>
<xsl:if test="$SetDate/root/DateTime">
<pfx:DateTime>
<xsl:value-of select="$SetDate/root/DateTime"/>
</pfx:DateTime>
</xsl:if>
</pfx:GetInformationResponse>
</xsl:otherwise>
</xsl:choose>
|
Mapping table
| Target | Source |
|---|---|
| /root/DateTime | current-date() |
Mapping tree
| Mapping |
|---|
root DateTime = current-date() |
Source code
| Mapping |
|---|
<root xmlns:pd="http://xmlns.tibco.com/bw/process/2003" xmlns:xsl="http://www.w3.org/1999/XSL/Transform" xmlns:xsd="http://www.w3.org/2001/XMLSchema" xmlns:pfx="http://www.tibco.com/schemas/pantherbw/PantherBW/ProcessDefinitions/Schema/Schema.xsd" xmlns:ns="http://www.tibco.com/pe/EngineTypes">
<DateTime>
<xsl:value-of select="current-date()"/>
</DateTime>
</root>
|
